AutoCAD Electrical 2018 – Connector Sizes

ARKANCE Experts Team
ARKANCE Experts Team
  • Updated

By Miles Nicholson


When you insert a parametric connector inside of AutoCAD Electrical, you can change the dimensions of the connector. The dimensions are not only saved within the current session but also future sessions of AutoCAD Electrical and the settings may be copied to other users’ installations if necessary.
