MEPworx Wiring – Revised and updated Siemens CPD DB

By David Wren

The latest version of the Siemens CPD DB has now been raised to Siemens 2023.
This new version of the CPD DB has been updated with the breakers listed below:

MCB 5SL

• 5SL Type B Ics=6kA
• 5SL Type C Ics=6kA
• 5SL Type B Ics=10kA
• 5SL Type C Ics=10kA
• 5SL Type D Ics=10kA

RCBO 5SU1

• 5SU1 RCBO-C Icn=4.5kA
• 5SU1 RCBO-B Icn=6kA
• 5SU1 RCBO-C Icn=6kA
• 5SU1 RCBO-B Icn=10kA
• 5SU1 RCBO-B Icn=10kA
• 5SU1 RCBO-C 30mA 4 Pole
• 5SU1 RCBO-C 300mA 4 Pole
• 5SU1 RCBO-D 30mA 4 Pole
• 5SU1 RCBO-D 300mA 4 Pole

RCBO 5SV1

• 5SV1 RCBO-B Icn=4.5kA
• 5SV1 RCBO-C Icn=4.5kA
• 5SV1 RCBO-B Icn=6kA
• 5SV1 RCBO-C Icn=6kA

AFDD-MCB 5SV6

• 5SV6 AFDD- MCB Type B 6A- 40A Icu=6kA
• 5SV6 AFDD- MCB Type C 6A- 40A Icu=6kA
