MEPworx Wiring –Updated Hager CPD DB

by David Wren

In keeping with on-going development, regarding new and updated Circuit Protective Device Databases (CPD DBs), we are pleased to announce an updated Hager 2024 CPD DB, as detailed below:

• Added the new ADC9 - 6kA RCBO - Type C curve with Bidirectional Type A earth trip.
• Added the new ARL 6kA AFDD-RCBO - Type B curve with Type A earth trip, including
  back- up data.
  (The 'L' version of the AR breaker has a longer Neutral fly-lead for use in TPN panels.)

Other added RCBOs;

• ADB4 10kA RCBO - Type B curve with Type A earth trip. A new replacement for the older ADA RCBO, which is now marked as obsolete.
• ADC4 10kA RCBO - Type C curve with Type A earth trip. A new replacement for the older ADA RCBO, which is now marked as obsolete.
• ADD4 10kA RCBO - New breaker. Type D curve, with Type A earth trip.

Added the new HW2 & HW4 ACBs
These ACBs are available with the following combinations of features:

• Ratings from 630A to 4,000A
• Breaking capacities, 55kA up to 120kA
• With trip units LSI or LSIG

Please note that with the introduction of the new HW2 & HW4 ACBs, all the older HWT ACBs in the database are now marked as ‘Obsolete’.
