Revit 2022 – New feature – Walls: Suppress display of non-structural components

by Dennis Collin

A much-requested feature for Revit is the ability to supress the display of non-structural elements within walls. With the image displayed below we see a typical Cavity wall with both plaster, air gap and brick façade component displayed.

Fig. Plan view showing typical cavity wall

However, with Revit 2022 there is now a new subcategory called Non-core layers, suppressing this component within Visibility Graphics overrides will just display the structural elements in that view. Whether elements are structural or not is controlled in the type properties, structure section of each wall family.

Fig. New Subcategory in Visibility Graphics

This display option can easily be incorporated into view template settings.

Fig. Same wall with display of non-structural elements supressed
