Revit 2022 – New feature: Grids in 3D Views

by Dennis Collin

A few Revit versions ago, level objects were set to be visible in 3D views. With the release of 2022 last week Grids are also visible. To make them visible , click the show grid visibility controls and select the appropriate intersecting level.

Fig. Setting Grid objects to be visible within a 3D view.

The latest release of Revit has many other new features and improvements, a selection of some of these improvements are listed below. I will post about these and other developments in more detail over the coming weeks.

• Revit Built-in PDF Exporter.
• Show Wall Core Only.
• Tapered Walls.
• Filter by Family and Type in Schedule View.
• Split Schedule Across Sheets.
• Remember Last Used Tab in Material Browser.
• Load Autodesk Family Navigation Tools.
• Revision Numbering Enhancements.
