AutoCAD 2022 - The Fillet Command – No Trim Mode

Marketing
Marketing
  • Updated

By John Flanagan


Understand the Trim Mode Options


The no trim mode setting allows me to place the fillet arc without deleting or trimming any of the existing elements.


Trim

Selected objects or line segments are trimmed to meet the endpoints of the fillet.


No Trim

Selected objects or line segments are not trimmed before the fillet is added.


The current value is stored in the TRIMMODE system variable.
