AutoCAD Electrical Localiser 2026

by Miles Nicholson

The ARKANCE UK Localiser is a unique application designed to enhance AutoCAD Electrical by adding functionalities and content tailored to European standards. The application is available to ARKANCE subscribers ONLY. Please contact support.uk@arkance.world for a password to access the downloaded content.

For further information on the AutoCAD® Electrical Localiser please refer to the following articles:

What’s New In the Electrical Localiser 2026

Localiser Overview

New Features & Improvements:

• New enhanced & intuitive installer to allow installations as Standalone, Network, and Additional PC installations.
• A new Flip Pipe Number command has been added to the the Pneu/Hyd/PID + ribbon
• A new Circuit Clipboard pane has been added to the Pneu/Hyd/PID + ribbon mirroring the functionality of the Schematic ribbon
• A fault in the Pneu/Hyd/PID + ribbon Symbol Builder command has now been corrected

These commands mirror those found on the Schematic ribbon, but allow pneumatic, hydraulic, or P&ID engineers to minimise switching between ribbons.

Additionally, for the electrical engineer, enhancements that boost clarity in drawing documentation have been added to the ARKANCE UK Localiser.

• New command Footprint Cross Reference has been added to the extras + ribbon.
• The blocks used to add intelligence to footprints, whether new or existing, now include an XREF attribute to facilitate the ability to cross reference the footprint with the associated parent schematic component.
•

System Requirements:

The Electrical Localiser requires AutoCAD® Electrical 2026/2025/2024 to be already installed. The PC specification is identical to the requirements of AutoCAD® Electrical 2026/2025/2024.

The product is via digital download.

64-bit OS that follows Autodesk's Product Support Lifecycle policy.
