AutoCAD Electrical 2021 – Signal Error List

by Miles Nicholson

The signal error list runs a report that lists all the signal source and destinations used on the set of the project drawings. It provides an exception report list that highlights problem areas such as a destination signal with no source found or a source signal that does not tie to a destination. It’s extremely useful when analysing your connections especially on a larger project where it is less obvious with potential mistakes. You can surf to the specific problems to analyse the potential exceptions.
