Civil 3D 2022 - Profile View Chainage Text Height

By Justin Doughty

The Profile View in Civil 3D is a very easy tool to use to show the design. However if just one element needs changing to show different data or a different style, there are many levels of customisation that need to be explored. This series of blogs will take typical examples of changes and show how they are configured.

The profile view chainage text height is configured in the Label Style of the Band Style. This has to be done for each band style and then each chainage in each style:
