Revit 2024.1 – Improved Text Alignment for Multiple Text Notes

By Dennis Collin

Revit 2024.1 brings many improvements for working with models of all disciplines. In previous versions of Revit getting text notes to line up or justify to different edges was problematic. However, with Revit 2024.1 multiple text notes can be selected and align to suit view requirements.

Although previous versions of Revit did provide some alignment options it was a case of editing one element of text at a time. With 2024.1 the multiple alignment option mimics some capabilities that other software possesses like AutoCAD.
